Technics SE-A5 MK2 eindversterker

Te koop aangeboden: exclusieve Technics SE-A5 MK2 eindversterker. In een mooie conditie. Geheel nagezien door Audio Service Elst.

• inruil cassettedeck Technics RS-B100 mogelijk
• inruil digitale camera Fujifilm X100V mogelijk

Specificaties:

General

• Manufacturer: Technics
• Model: SE-A 5 MK 2
• Type: Power amplifier
• Years of manufacture: 1983 - 1988
• Made in: Japan
• Color: Black
• Power consumption: 950 W max.
• Dimensions: 430 x 178 x 416 mm (WxHxD)
• Weight: 18.4 kg
• Original price approx.: 2'200 DM

Connections

• Number of inputs: 2
• Input sensitivity:
• Line In fixed: 70 mV, max. 1 V, 47 kOhm
• Line In adjustable: 70 mV, max. 1 V, 47 kOhm

• Number of outputs:
• Headphones: 800 mV, 330 Ohm
• 2 speaker pairs

Technical Data

• Continuous power
• 8 Ohm: 2x 150 W (20 - 20'000 Hz, 0,002 %)
• 4 Ohm: 2x 180 W (20 - 20'000 Hz, 0,003 %)

• Dynamic power
• 8 Ohm:
• 4 Ohm:

• Total harmonic distortion: 0.003 % (nominal power, 20 Hz - 20 kHz)
• Attenuation factor: 50 at 8 Ohm
• Frequency response: DC - 150 kHz, + 0 dB, - 3 dB
• Power bandwidth: 5 Hz - 100 kHz (8 ohms, both channels, 0.007 %)
• Signal-to-noise ratio: 121 dB (IHF-A)
• Channel separation 75 dB
• Display range instruments: - 60 dB - + 5 dB

Special Features

• Double-mono construction throughout
